DJI E-Port Development Kit

£44.00

The DJI E-Port Development Kit enables developers to integrate custom hardware and systems into DJI aircraft by converting the E-Port into multiple standard hardware interfaces. This facilitates seamless connection of external devices and supports SDK development and debugging.

The DJI E-Port Development Kit enables developers to integrate custom hardware and systems into DJI aircraft by converting the E-Port into multiple standard hardware interfaces. This facilitates seamless connection of external devices and supports SDK development and debugging.

In order to process your order, please complete the product enquiry form below. A member of the team will get in touch using your contact details to organise the payment and shipping of your order.

Highlights

  • Converts E-Port to XT30 power outputs, USB 2.0, and UART/PPS signal ports.

  • Supports hardware integration and SDK development.

  • Compatible with DJI Matrice 350 RTK, Matrice 300 RTK, and Matrice 30 Series.

What's in the box?

  • E-Port Adapter Board ×1

  • Pin Header Protector ×1

  • E-Port Coaxial Cable (150 mm) ×1

  • XT30 to USB-C Power Cable (300 mm) ×1

  • XT30 to DC5.5 Power Cable (300 mm) ×1

Specifications

  • Adapter Board Dimensions: 55×40×9 mm (L×W×H)

  • XT30 VCC Power Output:

    • DJI Mavic 3E/3T: 12–17.6 V/4 A

    • Matrice 30 Series: 19.2–26.1 V/4 A

    • Matrice 300 RTK: 24 V/4 A

    • Matrice 350 RTK: 24 V/4 A

  • XT30 12V Power Output: 12 V/2 A

  • XT30 5V Power Output: 5 V/2 A

Compatibility

  • DJI Matrice 350 RTK

  • DJI Matrice 300 RTK

  • DJI Matrice 30/30T

Tips

  1. Ensure the adapter board is positioned appropriately to avoid short circuits from contact with the aircraft arm.

  2. When integrating the adapter board into a payload, design a heat dissipation system and a metal shielding cover.

  3. If any sparks, smoke, strange smells, or other abnormalities are detected, disconnect the adapter board from the power source immediately.

  4. When all three XT30 power ports are used simultaneously, the total output power should be less than the maximum output power of the aircraft. Ensure payloads are developed within the output specifications.

The DJI E-Port Development Kit is an essential tool for developers seeking to expand the capabilities of DJI aircraft through custom hardware integration.
